30″ 3-in-1 Pan and Box Brake – Slip Roll, Shear, and Sheet Metal Bending Machine (Model MMCB3016) Product DescriptionThe MechMaxx MMCB3016 3-in-1 Sheet Metal Machine combines a slip roll, sheet metal shear, and pan & box brake into one compact and versatile metalworking system. Designed for fabrication shops, HVAC technicians, and DIY metalworkers, this machine allows users to bend, cut, and roll sheet metal with a single piece of equipment.With a 30-inch working width and the ability to handle up to 20-gauge mild steel, the MMCB3016 is ideal for small fabrication projects, ductwork, sheet metal parts, and general workshop metal forming. The integrated slip roll allows operators to create cylinders, cones, and curved components, while the shear and brake functions provide precise cutting and bending capabilities.Built with a heavy-duty cast-iron frame, this machine offers excellent durability and rigidity while maintaining a compact footprint suitable for garage workshops and smaller fabrication spaces. Whether performing bending, cutting, or rolling operations, the MMCB3016 provides reliable performance and professional-grade results. Three Machines in OneThe MMCB3016 combines three essential sheet metal tools into a single efficient machine.• Slip roll for forming cylinders, cones, and curved shapes• Sheet metal shear for precise cutting operations• Pan and box brake for bending sheet metal components• Adjustable fingers for forming boxes and trays• Manual controls for smooth and precise operation• Compact design ideal for small workshopsThese integrated capabilities allow fabricators to perform multiple metalworking operations without needing separate machines. Durable & Reliable ConstructionBuilt for long-term durability, the MMCB3016 features a rigid cast-iron frame and precision components designed to provide consistent results across all three functions.• Heavy-duty cast iron construction for rigidity and stability• Surface-ground components for smooth operation• Reversible upper shear blades for extended blade life• Adjustable blade settings for different materials• Designed for fabrication shops and DIY metalworkingThis durable construction ensures dependable performance for metal fabrication and workshop applications. Technical SpecificationsSlip Roll FunctionMinimum Rolling Diameter: 1.53″ (39 mm)Maximum Rolling Thickness: 20 Gauge Mild SteelWire Sizes: 3/16″, 1/4″, 5/16″Roller Type: Slip rollers for forming cylinders and arcsBrake FunctionMaximum Bending Angle: 90°Maximum Bending Thickness: 20 Gauge Mild SteelMinimum Reverse Bend: 1/2″Maximum Box Depth: 2-3/8″Shear FunctionShearing Capacity: 20 Gauge Mild SteelShear Length: 30″Blade Type: Reversible upper blade with fixed lower bladeCutting Method: Moving upper blade passes fixed lower bladeConstructionFrame Material: Heavy-duty cast ironFinger Dies: Adjustable for box and pan formingSurface Finish: Precision ground for smooth operation
